The Authentic GDMods D.1 VW Box Mod is powered by Authentic YiHi SX600J Chipset and Compatible with 510 atomizer (24mm (max diameter) / 40mm (min height)). The GDMods D.1 VW Box Mod is powered by 1 x 18650 battery (not included).
| Quantity: | |
|---|---|
| Brand | GDMods |
| Model | D.Box |
| Color | Black |
| Product Type | VW |
| Compatiable Battery | 18650 |
| Thread Type | 510 |
| Variable Voltage (VV) | No |
| Battery Type | Interchangeable |
| Telescoping Mod | No |
| Power Output | 1~60W |
| Display | 0.69" |
| Variable Wattage (VW) | Yes |
| Charge Style | AC/USB |
| Package | 1 x VW Mod |
| Weight | 85g (3oz) |
| Depth | 48mm (1.89 inch) |
| Height | 80mm (3.15 inch) |
| Width | 27mm (1.06 inch) |
510 threading connection
Compatible with atomizer: 24mm (max diameter) / 40mm (min height) (atomizer not included)
Powered by 1 x 18650 battery (not included)
Powered by Authentic YiHi SX600J Chipset
Fire Button: Side
Output Power: 1W~60W
Output Voltage: 1.0V~8.0V
Resistance Range: 0.1~3.0ohm
Output Current: 25.0A
Input Voltage: 3.20V~4.20V
Input Current: 0.5A~21.0A
Efficiency: 90%
Charging: TYPE-C On-board 5V / 2A / Upgrading
Screen on Current: 30mA
Quiescent Current: 1uA
Power Down Current: 1uA
Screen size: 0.69" OLED Display
Waterproof: YES
Fire Method: One regular fire button
Adjustment buttons: 2 buttons
Software Upgrade: YES (USB-C Supports SXLINK WIFI dongle)
Intelligent Curves: Power / Temp
Temp Control: YES
Temp Control Modes: Dynamic / Constant
Preset Temp Control wires: SS316L, Ni200, TCR
Customize Logo: TBD
Protection:
1. Reverse Polarity Protection
2. Output Short Protection
3. Low Resistance Protection
4. Battery Low Voltage Protection
5. Battery Overcharge Protection
6. Chipset Overheat Protection
